- 9K jumbo frames para aumentar as taxas de transferências de dados

- Portas Ethernet de 8 Gigabits

- 1000Mbps-Full-duplex, 10/100Mbps-Full/Half-duplex, Negociação automática, MDI/MDIX automático

- Suporta auto-detecção e antiguidade automática de endereços 8K MAC

- O controlo de fluxo IEEE 802.3x protege contra a perda de pacotes para transmissão de dados fiável

- Oferece montagem em na secretária ou na parede

- Instalação rápida e fácil

- Minimize a pegada de carbono com a tecnologia avançada de energia eficiente (IEEE.802.3az)

Standards & Protocols:
IEEE 802.3 10-BASE-T, Ethernet
IEEE 802.3u 100-BASE-TX, Fast Ethernet
IEEE 802.3ab 1000-BASE-T, Gigabit Ethernet
IEEE 802.3x Flow Control (full-duplex flow control)
IEEE 802.3az Energy Efficient Technology

Buffer Memory:
1024KB

Port:
8 x 10/100/1000Base-T RJ-45 Port

Indicator:
Power; Link/Active

Transmission Method:
Store-and-Forward

Power Input:
DC 5V, 1A, External Power Adapter

Power Consumption:
< 3W

Backplane (Gbps):
16Gbps

MAC Address Table:
8K

Performance
Packet Forwarding Rate:
1000Mbps port - 1,488,000pps
100Mbps port - 148,000pps
10Mbps port - 14,880pps

Jumbo Frame (K):
9K

Environment
Power Saving:
IEEE 802.3az Energy Efficient Technology: Active Link Detection; Cable Length Detection; Sleep Mode

Operating Temperature (°C):
Operating: 0°C ~ 40°C
Storage: - 40°C ~ 70°C

Operating Humidity (Non-condensing):
Storage: 5% ~ 90%
Operating: 10% ~ 90%

Installation:
Desktop and wall-mountable

Physical Specifications
Dimensions (W x D x H mm):
149.5 x 89 x 27 mm

Weight (g):
192g

Approval and Compliance
EMI/EMS:
CE, RoHS, FCC
